SW13 - Module Add JLR NCF29A1 Keys to RFA MCU Dump 2017-2025+

NEW*   SW13 - Optional  Module Add JLR NCF29A1 PEPS UWB or PSFOB NON UWB Unlocked Keys to RFA MCU Dump with RF & Keyless  Supported

[Sign in to view price]
NEW* SW13 - Optional Module Add JLR NCF29A1 PEPS UWB or PSFOB
Lock50 SW13 — Add unlocked NCF29A1 keys to the RFA dump
Add a new, unlocked JLR NCF29A1 key (PEPSFOB with UWB or PSFOB without UWB) into the RFA MCU D-Flash dump on the bench • remote + full keyless • 2017–2025
🔑 New / unlocked NCF29A1 keysRFA (Remote Function Actuator) D-Flash dumpRemote + keyless on the added key
Lock50 SW13 — add keys from the RFA MCU dump (NCF29A1, 2017–2025).
Lock50 SW13 — add keys from the RFA MCU dump (NCF29A1, 2017–2025).

What SW13 does

  • Adds an unlocked JLR NCF29A1 key — PEPSFOB (with UWB) or PSFOB (without UWB) — into the RFA (Remote Function Actuator) MCU D-Flash dump read on the bench.
  • The added key gets remote and full keyless on both RFA types — no UWB-off step, no software function on the car.
  • The RFA D-Flash dump is read off the bench and loaded into Lock50 (the RFA is the SPC, and if it is unlocked the SPC560B60L3 MCU is unlocked and the D-Flash reads out); the key is then added into the dump (SW05 / SW07 are the sister read / emulate functions).
  • Used / locked keys cannot be added with SW13 — that is SW14.

How it works

  1. Read the RFA MCU (SPC560B) D-Flash dump on the bench with SW05 / SW06 / SW07 (K8D2 / J9C3 / M9R3 families).
  2. Read the new key on the HW01 / HW04 antenna — it must be unlocked (check with SW02).
  3. Open SW13, load the dump, add the key into a free key slot and save the dump.
  4. Write the dump back to the RFA and refit — the key does remote and keyless straight away.

SW13 vs SW14 vs copy keys

Job Use Result
Add a new, unlocked NCF29A1 key to the RFA dump SW13 Remote + full keyless.
Add a used / locked NCF29A1 key to the RFA dump SW14 Remote + full keyless.
Emergency start needed (dead key battery start) HW13 (433 MHz) / HW14 (315 MHz) copy keys Copy an existing key onto a Lock50 change-ID key — the copy keeps emergency start.

Hardware, cars and years

  • Runs on HW04 (any package A to C+) and on HW01. The key is read on the tool’s own antenna — bench job, no car, no OBD.
  • Module: RFA (Remote Function Actuator) — K8D2 / J9C3 / M9R3 families, MCU SPC560B, D-Flash dump.
  • Keys: unlocked NCF29A1 PEPSFOB (with UWB) and PSFOB (without UWB), OEM or Lock50 HW15 (433 MHz)–HW28 (315 MHz).
  • Cars: Land Rover and Jaguar 2017–2025.

Key facts

  • Keys added through the RFA dump get remote + full keyless — locked or unlocked RFA, no UWB-off.
  • A key added via the dump route does not carry emergency start — for emergency start copy an existing car key onto HW13 (433 MHz) / HW14 (315 MHz) change-ID keys.
  • Unlocked keys only — used / locked keys go through SW14.

Related Lock50 functions

Function What it does & when you need it
SW14 Add used / locked NCF29A1 keys to the RFA dump.
SW05 K8D2 RFA SPC560B dump — read / unlock / precode.
SW06 J9C3 RFA dump — emergency-start key emulation.
SW07 M9R3 RFA dump — emergency-start key emulation.
SW02 Read the NCF29A key: part, frequency, locked status.
Official Lock50 Bench & Dump Programming Protocol
• Adding to Dump: Adding a key directly to a KVM, RFA, or BCM EEPROM dump is 100% FREE with any fixed-ID key.
• Copying from Dump: Copying an existing key from a dump to a Lock50 Change-ID key is 100% FREE (NO TOKENS NEEDED).
• Key-to-Key Copy: Duplicating an original unlocked key in the tool is 100% FREE (NO TOKENS NEEDED).
